The "Must Have" app for electronic engineers, hardware designers and others, who use Electronic CAD and EDA systems.
It allows you to view Gerber RS-274X plotting documents. The Gerber format is the de facto standard for "CAD to CAM" data transfer in the PCB (Printed Circuit Board) industry.
AndroCAD: Gerber Viewer doesn't support RS-274D (old Gerber format).
Demo version has restrictions.
Maximum file size: 200Kb.
Multilayers: off.
Disabled options: rendering, coordinates & grids, frame mode, unrestricted zoom.
Any Gerber-274X file must contains %MO and %FS markers!
Minimum System Requirements.
Android OS: 4.0
Display: 4.0"
Free RAM memory: 45 Mb (for Demo), up to 120 Mb (for Light/Pro).
AndroCAD Gerber Viewer can open Gerber-274X files, created by Altium Designer / Eagle / OrCAD / Protel / KiCad and others.
If you think you have Gerber-274X schematic file and it is not recognized by Gerber Viewer, please send it to us.
See our site and the video on YouTube for additional info.
