This application includes various steel connection drawings which is a curriculum for B.E Civil Engg 7th Semester VTU, Other Universities and various Autonomous institutions.

Front View, Top View, Left View, Right View, 3D View etc of the steel connections are added which makes the learner to understand the concepts of steel connections drawings easily.

Courtesy: Prof. G. Ravindrakumar

Below Topics are covered in this App.

I. Bases

1. Gusseted Slab Base

2. CLEAT

3. Slab Base

II. Column Battened

1. Battened Column Revit

2. Battened Column Welded

III. Column Lacing

1. Four Angle Lacing

2. Double Lacing

3. Double Lacing Channel Back-to-Back

4. Double Lacing Channel Toe-to-Toe

5. Single Lacing Rivet

6. Single Lacing Welded

IV. Connections

1. Beam Beam Rivet

2. Beam Beam Welded

3. Beam Column Rivet

4. Beam Column Welded

5. Stiffened Welded

6. Stiffened Rivet

7. Unstiffened Rivet

8. Unstiffened Welded

V. Plate Girder

1. Rivet Plate Girder

2. Rivet Plate Girder Horizontal

3. Welded Plate Girder

Hope It will help the learners of steel connections

All the Best for your exams!!!

If you have any doubts or find a fault or any suggestions of improvement please mail me to sanmobapps@gmail.com
